PNW-65CS2 6.5" Component Speakers, 100W RMS, 3 Ohms (Pair)
HomeStore

PNW-65CS2 6.5" Component Speakers, 100W RMS, 3 Ohms (Pair)

PNW-65CS2 6.5" Component Speakers, 100W RMS, 3 Ohms (Pair)

AudioControl has over 45 years of experience engineering top-quality audio components. Buckle up and get ready to embark on a wild new auditory adventure with AudioControl’s PNW speakers! Experience the vibrant landscapes of the Pacific Northwest through your music when you combine AudioControl’s legendary amplifiers with the new PNW series of speakers. Trust us, you’ve never heard sound quite like this before. The PNW line features an edge-enhanced steel frame for ultimate structural strength, a black anodized voice coil former for superior heat dissipation, and a linear double-roll surround for precise cone movement. Plus, the rigid poly mica-coated cone optimizes sound reproduction.

Worried about installation? Don’t be! Our speaker sets come with high-quality mounting hardware, so you can enjoy your new sound system hassle-free. The tweeter’s point source design even aligns the output of both drivers perfectly, resulting in better speaker alignment for amazing sound quality. Looking for the full package? Pair PNW with our Spike or Space series subwoofers for the ultimate in-vehicle listening experience. All of these features add up to a line of speakers that are not only impressive on paper but are sure to impress you with their detail, clarity, and volume every time you drive.

FEATURES

  • Edge-enhanced steel frame for added structural strength
  • Black anodized voice coil former for superior heat dissipation
  • Linear double-roll surround for precision cone movement
  • Complex FEA-designed high-efficiency motor
  • Rigid poly mica-coated cone for optimized sound reproduction
  • Rear dampened hybrid silk dome tweeter for extended frequency response
  • High-quality mounting hardware included

SPECIFICATIONS

Crossover Type                                    2nd order Linkwitz-Riley

Power                                                          100W RMS / 125W Max

DC Resistance (Re).                            2.3 ohms

Filter Type                                               HP / LP

Frequency Response                       60-20k Hz

XO Frequency                                       3.5kHz HP / LP

Slope (Octave)                                      -12 dB

Tweeter Voice Coil Diameter          25 mm

Midrange Voice Coil Diameter       35 mm



IN THE BOX: (2) PNW-65CS2 Speakers, Manual, Warranty



DIMENSIONS

  • Overall Diameter (w/o Grille) 6.5 in / 166 mm
  • Cut Out Diameter: 5.59 in / 142 mm
  • Mounting Depth: 2.36 in / 60 mm
  • Mounting Height (w/o Grille): 0.20 in / 5.2 mm
  • Mounting Height (w/ Grille): 0.86 in / 22 mm
  • Motor Diameter (w/ Cover): 4.6 in / 117 mm
  • Grille Overall Diameter: 7.05 in / 179 mm

DIMENSIONS FOR TWEETER

  • Overall Diameter: 2.13 in / 54 mm
  • Cut Out Diameter: 1.85 in / 47 mm
  • Mounting Depth: 0.63 in / 16 mm



California Proposition 65

  • To our California customers: Please view your Proposition 65 warning here.
$319.00
